Tuesday, 14 August 2018

A Bank of Max For Live Oscillators - revisited

When I created BankOSCmr0v01, I thought that it was quite a neat, simple multi-oscillator sound generator, and so I released it into the wild...

After a bug report, followed by careful investigations by myself, Ableton and Cycling'74, it looks like  we could not reliably generate the problem, and so I went back to playing with it and seeing where this took me - which is where it started to get really interesting...

The problem with large numbers of oscillators is always one of control. Additive synthesis suffers from this because there are lots of harmonics that you need to control. BankOSCmr has 32 oscillators, and so suffers from similar problems, although I was determined not to do a traditional 'separate envelope for each oscillator' and I was equally focussed on not going anywhere near the standard FFT-based 'draw a response' approach either - the beauty of having 32 separate oscillators with a few Hertz resolution across the audio band is that you have a very different audio palette to FFT-based generators. (Plus I have already done a couple of those!)

BankOSCmr0v03f



So I played around with logical extensions of what I already had, and this rapidly expanded into the control method that is in BankOSC0v03f. The main new additions are the Freq and Volume 'damping' controls, and these affect the way that the density of the oscillator frequencies and volumes are affected by the scanning across the oscillators. Low values of damping create thick clusters of frequencies, whilst high values of damping give more open, thin whips of frequencies. I also added a timed 'Update' function, which resets the frequencies and volumes of the oscillators to random values, just to add a bit of variety in how the oscillators can be controlled. You can also click on the 'New' (at the top of the Van De Graaf) to force a new set of random values for the oscillators.

And it was great fun. The additions allow a lot more control over the sound pallete that BankOSCmr could create, and widened the possible sounds as well. In fact, it felt like you could almost use it for performance as it was, and so I put it through 3rd hand, the automatic volume fader, and just played around for 12 minutes or so, capturing it on video.

The result is available on YouTube.

The video demo of BankOSCmr0v03f was recorded live, and the only effect is Zynaptiq's superb free SubSpace plug-in to add a bit of spatial variety (If I could afford it, then I would be using their astonishingly wonderful Adaptiverb instead, which I fell in love with at NAMM, and which comes incredibly highly recommended by me!). 3rd Hand is just an automatic volume control. In more skilled hands than mine, then the demo would be better, and there's a few warts in the audio (this is version 0v03 remember!), but this was my first time putting everything together of a live video demo...

So what's going on in the demo? Well, the Update time is set to just under 15 seconds, so there's a bit of timed underpinning in the background for much of the time, although I do turn it off, and then back on again, just to show how this is simple to do. Then I just explore the various controls. High and Low set the range of frequencies generated by the 32 oscillators, whilst the Time sets how long it takes for each oscillator to change frequency, so you can go from very quick jumps, to very slow glides. Freq and Volume control the damping, and the Run control sets how quickly the scan runs across the oscillators. Fill has two functions: above 0.1s it just generates ramp functions, whilst below that it generates random values. The ramps allow the generation of some very cool Shepard tones, as you can hear in the middle part of the demo. The random values can give some astonishing bell-like timbres, again in the middle of the demo. At the end, I break with convention, and keep altering things as the fade out progresses. One of my more commercial songs introduced a blistering lead solo just after half way through the final fade, just so that anyone who was listening got the feeling that there was more - kind of the reverse of Roxy Music's intro to Virginia Plain (Sound of lots of people looking this up on iTunes and Spotify...).

What intrigues me is that there are lots of videos on the Interweb that show people playing Modular synths live and 'DAW-less', whilst I haven't been able to find very many that show an Ableton Live plug-in being played live, sans any sequencing or pre-recorded backing. Well, now there is one. Enjoy!

Getting BankOSCmr0v03f

You can download BankOSCmr0v03f for free from MaxForLive.com.

Here are the instructions for what to do with the .amxd file that you download from MaxforLive.com:

     https://synthesizerwriter.blogspot.co.uk/2017/12/where-do-i-put-downloaded-amxd.html

(In Live 10, you can also just double-click on the .amxd file, but this puts the device in the same folder as all of the factory devices...)

Adaptiverb...

Adaptiverb is incredibly highly recommended, and comes from Zynaptiq.

Modular Equivalents

In terms of modular equivalents, then reproducing this functionality in my modulars either involved 32 VCOs and four 8-step sequencers, or advanced oscillators banks or sequencers that I can't count as 'basic' modules, so I would rate this version as being about 46 ME (or 12ME if bank oscillators are allowed, or 8ME with fancy sequencers!).


Buy me a coffeeBuy me a coffee




Sunday, 12 August 2018

Quantising MIDI controllers in a MaxForLive device for Ableton Live

Forums and Groups are interesting places to lurk. If you ignore the incessantly repeated questions and the obvious trolling, then you occasionally get a query from someone who wants to do something unusual and interesting, and can't see how to achieve it. Recently, just such an enquiry turned up on on one of the popular synthesizer forums, and here, belatedly, is a response.

The enquirer asked about how to make a movement-sensing MIDI controller more predictable or repeatable. If you have ever tried to use any location-dependent controller that relies on where you hold your hands in the open air, then you may already be resonating with the difficulty. If you have ever played a Theremin, then you probably already know one of the challenges: making rapid, precise and repeatable movements of your hand between a small number of locations in 3D space is difficult. There's also the 'two different actions at once' problem: making the 'pitch-controlling' movements as rapid as possible (but don't forget precise and repeatable!) with one hand, to reduce the portamento between notes (and making the pitching as accurate as possible), whilst at the same time, making slow back and forth 'volume-controlling' expression movements with the other hand. It's tricky to master, and one of the ways that the 'not in tune' pitch variability can be mitigated is to apply 'quantisation': constraining continuous values to a small set of fixed values. For note length then DAWs have quantisation as a standard function. For MIDI controller messages then I assumed that there would be lots of utilities readily available...

MIDIccQuant


MIDIccQuant_mr is a utility device for Ableton Live, produced using MaxForLive, which quantises MIDI controller messages. Version 0v01 is the first release, and quantises to 4 levels, mainly because the UI for more than this starts to get awkward - but feedback should tell me if this is not enough levels.

Here's the overall flow diagram for what is happening, with the relevant bits of the UI above or below:


MIDIccQuant can process any one of 15 inputs, and the choices are the basic low-end simple controllers: Modulation, Breath Controllers, Foot Controller, Data Entry, Expression, and the general purpose controllers. These are the sort of controller numbers that a lot of MIDI Controller devices will be mapped to. I have always disliked the way that many utilities expect you to know what the controller numbers are, and so MIDIccQuant shows a number in the lower left hand corner that indicates what controller number incoming messages are from. Assuming that you don't have more than one controller active at once, then all you do is wiggle the MIDI Controller (or move your hand if it is a movement/position sensor) and look at the number that is displayed. To make it even easier, then clicking on the 'Copy' button will set the 15-button pad to that controller. If you prefer, and you already know the controller number, then you can just select the appropriate number on the pad!

The big 'CC' button controls the output of the processed controller value. When it is bright, then the controller value is quantised and sent out as a controller message. When it is dim, then the controller value is not quantised, and passes through the device unchanged. There's a big vertical indicator that shows the controller value.

There are seven rotary controls for the quantiser: three that set the levels at which the quantisation happens, and four that set what value is output for each of the four output states. This is slightly different to the way that note length quantisation does, because for that there is an assumption that you want to quantise a note to either slightly shorter or slightly longer, and so if you have an input that is just slightly longer than an 8th note, then you would expect it to be quantised to an 8th note, or a dotted 8th note, or maybe even a quarter note, depending on the quantiser settings. But MIDIccQuant allows the result of the quantisation to be any of the 128 MIDI controller values, and so if you set the lowest level to 15, then that output will be active for any incoming controller values between 0 and 15, and this could be set to output anything from 0-128. Rather like the Theremin, this might require some getting used to, and so the recommendation is that you set the outputs to get higher as you move up in the device UI.

Let's look at levels and outputs in more detail. The three 'Limit' rotary controls divide the 0-127 MIDI Controller values into 4 Levels:


So the lowest level (Level 1) is from 0 to Limit1 (0-18 in this example). The next level is Level 2, from Limit1 to Limit2 (19-65). Level 3 is from Limit2 to Limit3 (66-103) and finally, Level 4 is from Limit3 to 127 (104-127). Note that although the Levels are always arranged from 1 to 4, where Level 1 always starts at 0 and Level 4 always ends with 127, the same is not true for the Outputs - you can put any value you like (0-127!) for any level. If an output always has steps that increase as the input increases, then it is called 'Monotonic', and so this quantiser is non-monotonic. So if you want Level 1 to output 127, and Level 4 to output 0, then MIDIccQuant will do this.


In the above example, on the left hand side, as the input controller values increases, the output jumps UP from 30 to 48, then jumps UP to 82, then jumps UP to 101. So it always goes up as the input goes up - this is monotonic behaviour.

The right hand side has swapped the outputs for Levels 2 and 3, so Level 2 is 82, whilst Level 3 is 48. So as the incoming controller value increases, it starts out outputting 30, then when the input reaches 18, the output jumps UP to 82. As the incoming controller continues to increase, the output stays at 82 until the input is 65, at which point the output jumps DOWN to 48. When the input reaches 103, then the output jumps UP to 101. This is non-monotonic behaviour.

All you then need to do is make sure the whatever device you are controlling is getting the quantised controller value. Remember that if the 'CC' button is bright, then it will be receiving quantised controller values, and so the usual 'just testing' technique of waggling the mod wheel (et.) may not work if your quantisation is set with extreme values. So, slightly counterintuitively, you need to click the 'CC' button so that it goes dark, which bypasses the quantisation, and then do the testing. When the target device is confirmed to be receiving the controller values, then just click again on the 'CC' button to restore the quantisation.


To make the utility more useful, then there is a second output. The right hand side is my standard controller mapper, which lets you optionally invert the controller value, add an offset, scale it with the  'Depth' control, and map this to any controllable parameter in Ableton Live (and unmap it, of course). The 'Quant' button controls if the output from the parameter mapping is quantised or not, which can be useful if you want to have different consequences from the controller in two different places. The big 'Param' button disables the parameter output when dim, and enables the output when bright.

To visualise the quantisation levels, there's a display that shows the four levels - it builds up as you input values, so if you change the levels, then you can click on the 'Clear' button to clear the display. This can also be used as a simple MIDI controller debug facility.


Getting MIDIccQuant_mr_0v01

You can download MIDIccQuant_mr for free from MaxForLive.com.

Here are the instructions for what to do with the .amxd file that you download from MaxforLive.com:

     https://synthesizerwriter.blogspot.co.uk/2017/12/where-do-i-put-downloaded-amxd.html

(In Live 10, you can also just double-click on the .amxd file, but this puts the device in the same folder as the factory devices...)

Modular Equivalents

In terms of modular equivalents, then reproducing this functionality in my modulars was quite a challenge to achieve using standard 'basic' modules. My best simplistic solution required 4 separate 'brute force' quantisers plus several utility voltage processors, so I would rate this version as being about 9 ME. I'm intrigued that many modular quantisers assume that you want to quantise to fixed identical steps and monotonic levels, but I'm sure that there are loads of exception devices out there...


Buy me a coffeeBuy me a coffee


Tuesday, 24 July 2018

Slow fades in live performance...

3rd Hand was inspired by a ‘drone’ concert that I attended. The opening ‘build’ took about 10 minutes, and was astonishingly effective - there’s something about a big sound that starts out quiet and gradually gets louder and louder! So I wondered how to do this in Ableton Live, and 3rd Hand is the result…



3rd Hand is a timed volume control. You press the ‘Up’ button and the volume goes up. You press the ‘Down’ button and the volume goes down. If you change your mind, then pressing the button again reverses the direction! You can set the time that it takes to go from silence to full volume from a few seconds to over 45 minutes. Yep, three quarters (fourths) of an hour. (For people who like to really let something build at its own pace…)

Because 3rd Hand is a volume control, then the first control, labelled ‘Output’ is a… volume control. It lets you set the maximum output, and has quite a lot of gain for maximum flexibility. Just set the Up time to a short time and press the ‘Up’ button, and wait until you get to the 100% ’Maximum volume’ level, and then adjust the Output control to the loudest you want to reach. 3rd Hand alters the volume of anything that you pass through it, so you should put it at the end of your effects processing chain.

The Up and Down time controls have a big range. Note that they don't have normal parameters shown underneath - instead the parameters are shown ABOVE the rotary controls. You can see this by altering the rotary controls - The Minutes and Seconds should change. If nothing seems to be happening when you press the Up/Down button, then make sure that the ‘M’ setting isn’t several minutes… The bug reports that I got from the beta versions were mostly along the lines of: ‘Doesn’t work. No output.’, followed by ‘Ah, I see!’ later on when they found that ‘M’ means minutes (and ’S’ means seconds).

There are four states. Starting from zero volume, they are:

Zero Volume.
Ready to Fade up. Press the 'Up' button to start fading upwards from zero.



Fading Up.
Note that the button has changed to 'Down', so you can press this at any time to abort the fade up, and 3rd Hand will fade the volume back to zero again. If you don't press the 'Down' button, then the fade up will just continue upwards.



Maximum Volume.
The fade will slow down and stop as it gets to 100%. Note that the 'Down' button is still available, so you can fade down now if you want, or leave it at Maximum volume for as long as you like... You can think of the Max volume state as 'Ready to Fade Down'...


Fading Down.
The fade down gradually slows as it gets near zero volume. Note that as soon as the fade downwards starts, the button changes to 'Up, so that you can abort the fade down (if you pressed the button by mistake, foe instance) at any time.


 When the fade down is complete, we are back in the 'Zero Volume' state, where we started.

And that's mostly it. 3rd Hand is probably the most sophisticated simple device you have seen, but it is intended to do it properly, reliably and flexibly.

Because just changing the volume is a bit limited, the remainder of the device is a standard parameter mapping controller. You use the big ‘Map’ button to choose a parameter in Live that you want to control, and the you adjust the ‘Depth’ to set how much effect it will have on the parameter, with maybe some Offset added. You can invert the way the parameter follows the volume change - Normal tracks the volume, Invert goes the opposite way. So, for example, you could start out with lots of revert and gradually remove it as the volume grows, or pan from one sid to the other, or add chorus/echo as the volume rises… Whatever works in context - I'm sure you can find something awesome to control as the volume builds...


3rd Hand is meant to be used in live performance - in the above example, it is being used to control the output of BankOSCmr 0v02, which kind of fits the 'drone' genre I mentioned right at the start of this blog post. You could use it otherwise, of course. (One immediate thought is to have one 3rd Hand on several tracks and to use them to bring stuff in and out slowly.) Anyway, enjoy big slow builds!

Getting 3rd Handperf_a_mr0v01

You can download 3rdHandperf_a_mr0v01 for free from MaxForLive.com.

Here are the instructions for what to do with the .amxd file that you download from MaxforLive.com:

https://synthesizerwriter.blogspot.co.uk/2017/12/where-do-i-put-downloaded-amxd.html

Modular Equivalents

In terms of modular equivalents, then reproducing this simple functionality in my modulars involved 2 VCAs and an Envelope Generator, plus a Button trigger, and a Utility voltage processor, so I would rate this version as being about 5 ME.



Buy me a coffeeBuy me a coffee


Sunday, 22 July 2018

Synth Recipe: 'String' Pads


Visit my Soundcloud page for a comparison of 'String' Pad sounds made using Sine, then Square, then Sawtooth, then Rectangular waveforms. Or visit: https://soundcloud.com/.../sine-square-saw-rect-pad-examples

For some time, I've been wondering about doing single page summaries of sounds, and a conversation on a forum persuaded me to do something about it. So here's an experiment - let me know if you find this useful and want to see more of this type of guide.



Buy me a coffeeBuy me a coffee




Thursday, 5 July 2018

My first visit to a Bank of Oscillators...

I have always been fascinated by sound generators. Over the years, I have done a lot of dabbling into FM, AM, Ring Modulation, Granular, FFTs and many other techniques, and what I have found is that the interesting stuff is often in the detail. So my previous forays into Reaktor produced large numbers of generators exploring lots of ideas, and I sometimes reach back into that abandoned era to provide inspiration for MaxForLive devices. This brings me to my latest sound generator, whose name tells you just about everything about it: BankOSCmr0v01.

A Bank of Oscillators...

Any sound generation method that uses large numbers of oscillators has a basic problem that can be boiled down into a simple question: How do you control all of those oscillators?' Additive synthesis is a good example: lots of harmonics means lots of things to control, and creating a powerful and appropriate 'high-level' user interface can be a difficult challenge. But my current research interest is in inharmonics, and so I wanted to explore ways of working with non-harmonically related frequencies.

After poking around in some of the quieter parts of the Max object world, I found ioscbank~, and decided that this might be suitably inspiring. The Max documentation showed filling the paired frequency and amplitude controls with random values, but I like my sound generators to produce dynamic evolving sounds, not boring static timbres. So I added scanning that swept across the bank of oscillators, gradually changing the frequency and amplitude of each oscillator, and slugged the interpolation of these parameters so that they changed slowly - and I got an interesting 'big bank of oscillator' sound that had a lot of promise.

One of the techniques that I learned when creating synth patches was to explore the extremes of the available parameters, and so I experimented with the rate that updates happened, with the interpolation time, and with the range of frequencies and amplitudes. Messing about with the amplitudes did not seem very interesting, and so I abandoned that and moved to the other parameters. (Anyone who is shaking their head at this point needs to move to the follow-up article to this one, where I realise that I nearly missed something big and went back to controlling the amplitude.) After adding some filtering and some additional tweaks, I had an interesting result that could make a quite broad range of not-so-ordinary sounds: BankOSCmr0V01.



BankOSCmr0v01's user interface is dominated by the large display in the centre, and this is not interactive at all. It is purely to show you what is going on for each of the 32 sine-wave oscillators that this version uses. The display shows the 32 oscillators from left to right, and each vertical shows the frequency as an orange square and associated bar underneath, and shows the amplitude (the volume...) as a purple square and associated bar underneath. Low frequencies and amplitudes are at the bottom, and high frequencies and amplitudes are at the top.

To control the oscillators, the controls on the left affect:
- the Rate at which the update sweeps across the oscillators from left to right
- the High and Low extremes of the frequencies of the oscillators
- the Time for the frequencies and amplitudes to change to the new values from the scanning
- a 'New' button to generate a new set of random values for frequency and amplitude (If you send a MIDI note to this device when the Rate is set to the slowest time (...all the way clock-wise: 'Run' changes to 'Stop'), then this triggers the 'New' button.)

On the right, there is a simple state-variable filter that provides low-pass, high-pass, band-pass and notch transfer functions, and has Frequency and Q controls, an finally an Output control that has a deliberately large range to partially compensate for having no controls over oscillator amplitude (and I should add a second hint about the next version here as well).

And that was that. A simple bank oscillator that generates a range of sounds using a small number of controls. Nothing particularly special so far, but then there's more coming up next time... and plans beyond that as well.

Media

Several people have asked me why I never post videos of my MaxForLive devices on YouTube, and I never had a really good reason why not, so I'm posting a simple video to my YouTube channel, which is really going to surprise my 34 subscribers! I will also do my usual SoundCloud example as well.

Getting BankOSCmr0v01

You can download BankOSCmr0v01 for free from MaxForLive.com.

The YouTube video.

The SoundCloud demo.

Here are the instructions for what to do with the .amxd file that you download from MaxforLive.com:

https://synthesizerwriter.blogspot.co.uk/2017/12/where-do-i-put-downloaded-amxd.html

Modular Equivalents

In terms of modular equivalents, then reproducing this functionality in my modulars either involved 32 VCOs and four 8-step sequencers, or advanced oscillators banks or sequencers that I can't count as 'basic' modules, so I would rate this version as being about 40 ME (or 10ME if bank oscillators are allowed, or 6ME with fancy sequencers!).



Buy me a coffeeBuy me a coffee




Sunday, 1 July 2018

An 'Extreme' Multiplying LFO for MaxforLive


LFOLFO is an experimental 'Multiplying' LFO. It is based on the idea that being able to switch the range of an LFO can be used to generate a number of interesting audio effects, and so the design is optimised to enable easy control of the Rate and Multiply controls. The prototype was produced as a response to a question posed by Russell Alderton on the 'Max For Live Users' Group on Facebook, and it has undergone extensive development since then.

The Rate (Frequency) of the LFO can be modulated via two controls: Rate and Multiply. The Rate control is a conventional frequency control, whilst the Multiply control has four modes that provide several ways to affect the frequency. A multiply value of 'x 1.' produces an output frequency as shown on the Rate control, whilst a multiply value of 'x 0.5' produces an output frequency of half the value shown on the Rate control, and a multiply value of 'x 2.' produces an output frequency of twice the value shown on the Rate control.

The Rate and Multiply controls both have their own dedicated Sub LFOs, which can be used to modulate them, and this is shown graphically in a display underneath the controls. The LFO output waveform is shown as a backdrop to the whole MaxForLive device, thus providing a 'history' of recent changes to the waveform.

Each Sub LFO has multiple output waveforms, and the waveform selection of Sub2 can be controlled by Sub1. The output waveform of the LFO itself can be selected using a vertical selector, or via two modulation modes: one that counts the number of cycles that have been output, and a second mode that uses a third Sub LFO (Sub3). Both modulation modes use a probability grid that can provide sophisticated control over the sequencing of output waveforms.

The output waveform can be further processed by three controls: Smooth, S&H and Decimate (which do what their titles suggest). Finally, Offset and Depth controls. plus an Invert button allow fine tuning of the range of effect on the controlled parameter - which is selected using the 'Map' button.

Sync

Conventional Digital Audio Workstation (DAW) LFOs are either free-running, or synched to the DAW transport. LFOLFO provides a different type of sync that is intended to explore an alternative approach. A selection from a number of timing sources can be used to reset the LFO waveform, and this provides an 'Event Sync' that gives a number of interesting ways working with musical events instead of being rigidly locked to a timebase.

The UI from left to right

LFOLFO has a lot of controls that it uses to provide a wide range of advanced functionality. The settings above are a good starting point for learning - they are a kind of 'Neutral' setting. From left to right, the controls are:

Storage

LFOLFO provides 9 'memories' that can be used to store and recall the state of all the controls. To store a setting, hold down the SHIFT key and click on one of the 9 boxes. Grey boxes are empty. Purple boxes contain a saved setting. The white box is the currently selected setting. If you over-write a box then the previous contents cannot be recovered - this is colloquially known as a 'face-palm' error.

Event Sync

The large selection box enables the selection of 'events' that can be used to reset the LFO output phase. The reset phase is set using the 'Phase' retry control that is underneath the selection box. The top selection is '=Not-Synched=' and this is the Free-Running mode. The next selection options are for MIDI Notes in the track clip:

- AnyNote resets the phase for any MIDI Note.
- AnyChange resets the phase for any new MIDI Note. Any repeated notes are ignored.
- Note0 only resets the phase for Note 0, the lowest MIDI Note. This note is not used very often...
- Note0Velo1 only resets the phase for a Note 0 MIDI Note with a Velocity of 1. A velocity value of 1 is very quiet.

The next selection options use the Sub LFOs. Sub1, Sub2 or Sub3 can be used to reset the phase of the LFO, as well as a special reset that uses Sub3 and the waveform cycle Count (shown on the far right hand side).

The reset happens as soon as the event is processed by the device, and the value can be set using he 'Phase' control. If the event frequency is less than the 'Rate' then one or more cycles of the output waveform will be output. If the event frequency is higher than the 'Rate' then cycles will not be completed because the reset will happen before the cycle can complete.

Sub1

The first sub LFO can be used to modulate the 'Rate' control. The 'Sub1' rotary control affects the rate of the Sub LFO, whilst the 'Depth' rotary control affects the amount of modulation. The selector box sets the output waveform. When Sub1 is used to modulate the 'Rate' control then a graphical display behind the rotary control will show the modulation.

The Sub1 LFO can also be used to control the output waveform of the Sub2 LFO. If the frequency of Sub1 is greater than Sub2, then Sub2 will output incomplete cycles of its waveform. The selection of the output waveform is in sequence, from top to bottom, and then repeats. No other waveform sequences are available in this version... The button has two settings: 'Off' has no effect on the Sub2 output waveform, whereas 'Mod' will repeatedly sequence through the four waveforms.

Sub1's modulation of the 'Rate' control can be used for a number of effects. Using a Sine waveform produces traditional smooth 'up and down' variation in the frequency of the LFO. The triangle waveform gives a more abrupt change of direction and gives a more synthetic effect. The two sawtooth waveforms are particularly good when Event Sync is used, because they can produce a number of 'rise' or 'drop' effects, where the frequency of the LFO rises or falls linearly. Note that one of the advantages of using Event Sync is that when the frequency of the events is less than the LFO 'Rate', then several cycles of the output waveform will be produced, whereas if the event frequency is greater than the 'Rate', then less than cycle of the waveform will be produced. So by adding MIDI Note events into the track clip, very precise control of the LFO output can be obtained.

Sub2

The second sub LFO can be used to modulate the 'Multiply' control. The 'Sub2' rotary control affects the rate of the Sub LFO, whilst the 'Depth' rotary control affects the amount of modulation. The selector box sets the output waveform. When Sub2 is used to modulate the 'Multiply' control then a graphical display behind the rotary control will show the modulation.

There are four modulation modes for the Multiply rotary control, selected using the horizontal selector box on the lower edge of the device:

- Linear is a conventional modulation where the modulation increases linearly.
- Power increases the modulation in powers of 2.
- PowerHalf increases the modulation in quantised half powers of 2.
- PowerQnt increases the modulation in quantised powers of 2 (0.25, 0.5, 1, 2, 4 8, 16...)

Rate

The Rate road control is the main control of the frequency of the LFO. The output frequency is shown in Hertz. The modulation is shown graphically underneath the control.

Multiply

The Multiply control is a secondary control for the frequency of the LFO. It is rather like a 'range' control, but it can be modulated, and the rate and character of the jumps in LFO frequency can be controlled via the waveforms and the Sub1-Sub2 modulation button. Careful use of the Multiply control is the key to making the most of the functionality provided by a Multiplying LFO. Yes, you can use LFOLFO to vary a parameter with slow, smooth up and down changes, but this does not exploit the device to its full potential.

Try increasing the Multiply rotary control in each of these modes to see the effect on the 'Multiply' value. The 'PowerQnt' mode is specifically designed to change the rate in powers of 2: x .125, x .25, x .5, x 1, x 2, x 4, x 8, x16...

Vertical bar

The vertical bar shows the LFO output at the current time, and is not a control.

Waveform

The large selector box in the centre of the device serves two purposes, dependent on the mode set by the 'Waveform Mode' selector on the right - which has three modes: Select, which allows direct control of the LFO's output waveform via the selector box; plus Count and Mod3, which both use the grid in the middle of the device to choose waveforms, and the selector box then becomes an indication of which waveform is currently being output. In the Select mode, the grid, plus the Columns, Sub3 and Count rotary controls all do nothing. In the Count mode, the Columns and Count controls set the number of columns in the grid, and the number of cycles of waveform output that need to happen before the waveform changes (controlled by the cursor moving across the grid). In the Mod3 mode, then the Columns and Mod3 rotary controls are active, setting the number of columns and the rate at which the cursor moves across the grid.

The Grid

The grid is only active in Count and Mod3 modes, and allows the sequencing of waveforms to be specified. White squares indicate which waveform will be output when the cursor is in each column, an the vertical Waveform selector box shows which waveform is currently being output. If more than one square in a vertical column in the grid is white, then the output is randomly chosen from the white squares. So if there are two white squares in a vertical column, then the corresponding waveform will be chosen 50% of the time, on average. If there are three white squares, then each waveform will be output 33% of the time, on average. In the example shown above, there is just one white square in each of the two active columns, and so the corresponding waveform is chosen 100% of the time. This means that in Count or Mod3 modes, the first waveform to be output will be the Saw Down, followed by the Saw Up.

If you draw a line of white squares from the top left hand corner of the grid to the lower right hand corner, then each waveform will be played in sequence, just as in version 04. If you draw the opposite line, then the sequence will be reversed. The grid allows you to specify any sequence of waveforms, plus it allows probabilistic control over waveforms, which allows long complex waveform outputs. In summary, LFOLFO provides humungous power for creating output waveforms!

Once the waveform has been controlled using one of the three modes, then further processing can be carried out on it. This happens in the darker vertical box containing the 'Smooth', 'S&H' and 'Decimate' rotary controls.

Smooth

The Smooth rotary control is a low pass filter that removes the sharp edges in the output waveform, but it also reduces the amplitude - so you may need to use the 'Depth' control to increase the size of the LFO output waveform. Remember that the 'Depth' control affects the output amplitude of the LFO waveform before the Smooth control.

S&H

The S&H rotary control adjusts the rate at which the LFO outputs its waveform. This has the interesting side effect of slowing down the scrolling speed of the background waveform display - but it does not change the rate or frequency of the LFO!

Decimate

The Decimate rotary control adjusts the resolution of the LFO output waveform. In the '0' position, then the LFO waveform is smooth, whilst increasing decimation values makes the output increasingly jagged until at '2.0' then there are only two values (maximum and minimum). You can still use the Smooth and S&H controls on a decimated waveform, so these three controls should be seen as a flexible way of adjusting the output waveform to your specific requirements.

Once the final waveform has been set, then the final section (on the right) does the mapping of the LFO waveform to the parameter that is going to be controlled by the LFO.

'Normal' or 'Invert' button

This button controls how the parameter is controlled by the LFO output. 'Normal' is the same as the vertical bar, whilst 'Invert' is turned upside down, so that high values of the vertical bar give low parameter values.

Offset

The Offset rotary control adjusts the output of the LFO. Normally this will be left in the default '0' position, but some parameters and other settings may require it to be changed. The output waveform display that forms the background to the device is the key to using the Offset control - you should adjust the offset so that the waveform is not clipped at the top of the bottom. (although you can use this as a deliberate effect if you wish)

Depth

The Depth rotary control adjusts the size of the LFO output (which is why it is the right-most control!), and 100% is at the middle position, so you can deliberately output larger values that will be clipped. The Depth and Offset controls will often be used together to get the exact parameter changes that are required.

Unmap and Map

The Unmap button is only available when a parameter has been mapped using the Map control. The Map button is easy to use - just click on it and then select the parameter that you want the LFO to control. A good starting point is filter cut-off frequency in the 'Auto Filter' device. When you have correctly mapped a parameter then the name of the parameter will replace the 'Map' text in the button, and the 'Unmap' button will become available. If you click on the 'Unmap' button then the mapping to that parameter will be lost - and the only way to remap it is to carry out the mapping process again.

Getting LFOLFO

You can download LFOLFO 0v06 for free from MaxForLive.com.

Here are the instructions for what to do with the .amxd file that you download from MaxforLive.com:

https://synthesizerwriter.blogspot.co.uk/2017/12/where-do-i-put-downloaded-amxd.html

Modular Equivalents

In terms of modular equivalents, then reproducing this functionality in my modulars took anything from 10 to 14 separate 'basic' modules, with lots of patch chords (and some limitations and compromises), so I would rate this version as being about 12 ME.



Buy me a coffeeBuy me a coffee




Wednesday, 9 May 2018

Synthesizerwriter resources

Here is a summary of some of my free resources that are available on the Internet, related to this blog:

This Blog!

Echo effects

Installing an .amxd file in Live

Pinterest: Blog Posts
Synthesizers (etc.) that I have played...
Synthesizers (etc.) that I have programmed...
Max For Live (M4L)
Ableton Live (Interesting things I found)
SoundCloud






Buy me a coffeeBuy me a coffee




Sunday, 29 April 2018

Four-Step Sequencer in Gen for the OWL Pedal

Normally this blog talks about an investigation that I have done, or describes the design and features of some software that I have produced. This posting is slightly different from this because I've finally got around to delving into Gen the 'next level deeper' bit of MaxForLive or Max, and I'm going to show you how I used Gen to create a simple four-step sequencer patch. Instead of just telling you about what I have made, this time I'm going to show you how I programmed it as well - so 'next level deeper' two ways! This is just an experiment, so what happens next depends on the feedback that I get, or don't get.

Okay, so I have known about Gen for a long time (since it was called gen~, in fact), and I have always kind of overlooked it. I'm sure I'm not the only person who glances at it and thinks that learning to program in it is going to require time to learn it, and given the plethora of programming languages that I already know, acquiring yet another one is revisiting that 'start at the bottom yet again and claw your way up to the point when you can actually program things that almost do some of what you intended' learning curve that I have climbed many times before.

Just as in writing a novel, learning Gen requires something that breaks the hero/heroine of the story out of their normal humdrum ordered world, and forces them to go out and have an interesting adventure instead. In my case, the trigger was a casual conversation with a name producer, who said that what they really wanted was something that would let them do [possible subject of a future blog posting]. I made the mistake of saying that you could easily do that as a MaxForLive plug-in, and they pointed out that in this particular application, they had to be DAW-less, and so the trap was set. I then said that there were ways of doing this without needing a laptop or computer, and they said: 'You're on!' The trap was sprung and I was caught. I was committed to going on an adventure...

At the back of my mind, driving my confident assertion: 'there are ways', were the various hardware platforms that let you program them, not in Max, but in Gen. Things like the MOD Duo, or the Rebel Technology OWL Pedal. After comparing the specifications and the prices, I went for the OWL Pedal as my first test development platform, leaving the MOD Duo as a potential future addition to my portfolio.


Rebel Technology OWL Pedal

Rebel Technology describe themselves as a London based tech collective creating radically innovative music electronics since 2009', so they immediately sounded interesting - and they were at the 2017 SynthFest UK in Sheffield too! Alongside a variety of Eurorack modular stuff, they also do a completely programmable microcontroller-based development platform called OWL, that is available as a pedal or as a rack module (and more variations coming up soon). I went for the OWL pedal, and after the usual 'wait for the postman' delay, I soon had one. Having a piece of hardware kind of ups the commitment level, so I read all the documentation, watched their YouTube videos, and generally immersed myself in Gen. [Montage of time passing whilst being immersed in Gen...]

What I discovered was interesting, and there was an annoying little 'told you so!' voice at the back of my mind that kept reminding me what Cycling '74 have always said about Gen: that it isn't as scary as people think, and that it enables you to do amazing things, but that the one enabling thing you need to learn is a different way of looking at programming. In the case of Gen, that 'different way' is having to think about doing everything at the sampling rate, and that's quite a fundamental change in the way you conceptualise things. It's a bit like learning to hand-craft web-pages using only HTML, and then discovering that you've done it all wrong because you should have been using CSS for the layout, and HTML for the content.

My learning style hasn't changed much over the years. From the Intel 8080 onwards, my first program has always been a 'Hello World!' type of simple test, and then I have iteratively added bells and whistles (sometimes literally) until I eventually get to that 'do some of what you wanted' point. This method works for the small projects that I tend to work on, but there are lots of other ways of learning and programming that may suit you better. Whatever works for you.

So as my first patch, I wrote a patch for the OWL pedal (and it should work on the modular rack module too) that used an Expression pedal connected to the OWL Pedal to control the volume of an audio signal passing through the OWL pedal. Yep, 'Hello World!' for audio on the OWL pedal. Here's the basic patch, written in Gen:


Now it isn't immediately apparent when you first look at the patch, but there's something really interesting happening here: all of this is audio signals sampled at 48 kHz. So there are two audio inputs (in 1 and in 2 for the left and right input channels of the pedal), and these are connected to two multiply boxes (which contain just '*') and the output of the multiply boxes are connected to the two audio outputs (out 1 and out 2 for the left and right output channels of the pedal). So for every sample (48 thousand times per second), the in 1 audio input sample value is multiplied by the multiply box and the output goes to the out 1 audio output. If you multiply something by zero then you get nothing out, and if you multiply something by one then you just get the original value out. The source of this 'multiply' value is the Expression pedal (Exp). So this means that 48 thousand times a second, the position of the Expression pedal is sampled, and that sample value (between 0 and 1) is used to multiply the audio sample value from in 1 and in 2, an the outputs get sent to out 1 and out 2. That's 96 thousand multiplies happening per second inside the Owl pedal so that the volume of the inputs can be changed by the Expression pedal. Also, it means that if the Expression pedal potentiometer is even slightly imperfect, then we aren't going to get a smooth volume change, because the Expression pedal is sampled for each and every sample! Any noise or bad connection in the potentiometer is going to give the wrong value for the multiply value, and the output will jump up and down in volume. This patch design has lots of scope for improvement!

I followed this with a second patch that used the Expression pedal to pan the audio signal from left to right, and which used one of the OWL pedal's four control knobs to set the 'pan' law so that you had some control over how abruptly or smoothly the panning happened. Here's the basic patch:


This patch sorts out some of the problems in the first patch by adding a few extra boxes - compare the two patches first so that you can see what the changes are... The Expression pedal is now passed through a 'slide' box. This smooths the value so that any sudden jumps don't appear at the output. The final outputs from the multiply boxes are now limited to +1/-1, so if the multiply value somehow gets bigger than 1, then we aren't going to get excessively loud outputs - just distortion limited to +1/-1. The previous patch treated the two channels the same, but here we want to pan from one channel to the other, and so the smoothed Expression pedal sample is inverted for the in 1/out 1 (left) channel using the box with '!- 1.' in it. What this box does is subtract the Expression pedal value from 1, so a value of 0 outputs a 1, and a value of 1 outputs a 0. (This is just a weirdness of the way that Max does this type of function - just think of it as 'inverting' the value) So as the Expression pedal goes from 0 to 1, then the two channels will get opposite multiply values.

Unfortunately, pan isn't quite as straightforward as this in practice. So here's a revised version that sounds much better - and notice the extra multiply boxes, two new boxes and a new control...


What those boxes do is change the 'pan' law - the amount of overlap as the audio is panned across the stereo image. What happens is that the smoothed D' control knob on the OWL pedal is used to control if the law is linear or uses a quarter sine wave 'non-linear' law. (this is what the 'expo' box is doing). This isn't a perfect way of doing this, and there are much better ways of doing it, but it is simple and works quite well for my ears.

(Don't worry about going back and re-reading this explanation as you trace through the patch diagram  - there's a lot happening here, and as I have said too many times already, it all happens 48 thousand times per second!)

Having said that Gen is a 'deeper level' than Max, then it is probably time to show how Gen fits into the Max programming environment. Here's the Max patch that the Gen code is 'inside':


As you can see, the Gen code looks just like any other Max object, and the programming environment is familiar. It's just that things work a little bit different inside the 'gen' object... At the level of the Max patch, then we set up the inputs and outputs, and you can see that I have left a couple of number boxes and 'scope' objects in the patch, ready for using to view what is happening inside the Gen object -
which is the little box on the mid left hand side that I have put a purple rectangle around.


Gen doesn't provide the same depth of assistance as Max does, and so you need to do a bit more work to monitor what is happening inside a Gen object by using extra in or out objects. I think of it as a bit like trying to do things through the letterbox in a front door... I will try to show how this works as we go along, because it is one of the key skills to have when developing Gen, and it is easy to overlook when concentrating on the Gen code itself...

(It is also important to point out here that the OWL Pedal is only going to do the stuff inside that 'gen~' box. Some of the standard Max functionality isn't implemented in Gen for a variety of reasons, and so you need to approach things slightly differently - so it isn't just a case of putting standard Max objects inside that gen~ box, and you can't add Max objects outside of the gen~ box and expect them to work. 'Inside the gen~ box' is the key to this.)

My next patch took one of my old MaxForLive patches, and turned it into Gen. I had to do quite a bit of user interface simplification in order to cope with only having four control knobs, an Expression pedal and a pushbutton, but the result was quite encouraging: a stereo delay box with an unconventional way of doing things, and some quite unusual sounds. Rather than bore you here with yet another 'unique' delay patch (for some reason, the world is full of delay patches whose creators think are amazingly different),  then it felt like time for some more novel writing 'advance the plot' activity. If you are interested, then you can find the patch in the online library for the OWL devices - I'm called 'registration' because that's the email account name that I used. I'm also going to upload it to my Github repository at some stage...

Anyway, having told you about all of this preparatory work, it was now time for the next step nearer to what I had been so confident I could make for that producer. I took an idea and turned it into a patch, without basing it on a tutorial. This patch is the real topic of this blog post!

Four Step Sequencer

The OWL pedal has four control knobs, so it makes a four-step sequencer an obvious choice, and I wanted to make something self-contained: a step sequencer plus a simple sound generator. Using the pushbutton as a tap tempo source leaves just the Expression pedal as a possible timbal control. So if you have only one control, what gives the widest range of sounds?

After a bit of experimentation... Okay, after a lot of messing about... I dragged myself away from my modulars and decided on a slightly unconventional approach influence by Reaktor-style sound generators (Look up 'Flintpope' for some amazing examples!). I would use that single remaining control to set the rate of an LFO that sweeps a resonant low-pass filter past a pair of detuned oscillators, which is quite a lot of indirection... This means that this patch is more self-contained, and a bit more like a factory demo than a generically useful patch (and I've done various bits of paid 'impressive demo'-oriented work over the years), but as a learning patch, as something for people to tweak, to derive other patches from, then I think there is huge value in demo patches, especially when they aren't buried in reverb.

So how do you do timing in a the world of Gen? If everything is happening 48 thousand times per second, how do you work at a slower rate? The solution I chose is to just use a counter so that we slow down those thousands of times per second into something that works at a more human-oriented rate. You can do this in gen~ by using the 'phasor' object, which is a counter that counts from 0 to 1 at a rate set by a clock rate derived from the processors chip's master clock. There are lots of other ways to do timing in Gen - using the 'phasor' object is just how I did it in this case. Let's start by looking at the whole finished patch:


Okay, so there's lots more happening in this patch! So let's break it down into sections and look at each of those in isolation.


Top right deals with the timing, and that's where we will start. Across on the top left is the sequencer, and the lower half is the audio section.

Let's start with the timing. There are two linked timings that we need: one to produce the 4 steps that we will use for the sequencer timing, and another one to produce the envelope timing for the notes played by the sequencer. The sequencer timing is the easier of these to understand, so let's start with that.

Step sequencer



The box at the top right is the illuminated push-button in the centre of the OWL pedal - not to be confused with the big chunky foot-switch that can be used to bypass the pedal, in standard guitar-pedal style. The little pushbutton outputs zeroes normally, and ones whenever it is pressed. This appears at point (A) in the Gen code, and on the timing diagram below.


The output of the push-button goes into a pre-prepared 'encapsulated' gen~ object (from a Rebel Technology tutorial example) that measures how many 48 kHz clocks happen between presses of the push-button ('taps' in tap-tempo-speak) - a 'tap-tempo' box. The 48 kHz clock is the master timing source in the microprocessor used inside the OWL pedal, so this is how fast we sample those push button presses, and the measurement of the number of clocks that this gives us is thus the 'time' between buttons presses - in other words: beats.

We will be using the Max/Gen 'phasor' object to do our timing. The 'phasor' object produces a sawtooth waveform at a rate set by a 'frequency' input. Essentially, it is just a counter that starts at zero and counts upwards. But the 'phasor' Gen object that we are going to use to produce all our timing requires a frequency input, and all we have from the tap tempo is a time - so how do we convert time to frequency?

By dividing the 'time between push button presses (beats)' by the 48 kHz sample rate (Gen's variable for this is called 'samplerate'!), then you get the frequency of pressing the push-button. Assuming four beats per bar when the push-button was tapped, then this frequency is four times too fast, so we need to have a division by 4 - this will give the correct frequency for a complete bar from the phasor object.

Here's a quick aside about tempo and frequency.

Unfortunately, tempo isn't expressed in frequency - it is normally in beats per minute, and our frequency is going to be in Hertz. Let's go through this with some real-world numbers. Suppose the time between taps is 1 second, This means we are tapping at 60 beats per minute, because that's once every second for 60 seconds to fill the minute. 60 taps per second is 1 Hz, or one cycle per second. If we tapped twice as quickly, then the time between taps would be half a second, and in the 60 seconds in a minute, we would have tapped 120 times. 120 taps per second is 2 Hz.

The last thing we need to think about to produce the frequency for the phasor object is the length of a bar. So far we have figured out that 120 bpm is 2Hz, but if we have 4 beats per bar, then the bars per minute is going to be a quarter of 120, which is 30 bars per minute. We want the phasor object to produce one sawtooth per bar, so that's why we want to set the phasor object to run at a quarter of the beat frequency that we have measured using the tap tempo.

If you plot the time from the output of the tap tempo against the frequency that we need to drive the phasor for one sawtooth per bar, then it looks like this:

tap tempo time per beatphasor frequency
2.00.125
1.00.25
0.50.5
0.251.0
0.1252.0



And this shows us how time and frequency are related: it is called an 'inverse' relationship. As the time between taps gets longer, the frequency goes down, whereas as the time between taps gets shorter, the frequency goes up.

And back to the sequencer...

The conversion of the beat frequency to what the phasor needs is done by the box that contains '!/ 0.25'. 0.25 is 1/4, which takes care of the 4 beats per bar.



The 'phasor' object in Gen works much the same as in Max - it outputs a rising count at a rate that depends on the input. In this case, the rate is set by the tempo, and so we get a sawtooth (rising count) that resets every bar, starting at 0, and rising up to 1 (I'm going to totally ignore the internal representation of numbers inside the OWL pedal - because you don't need to know about 'floating point representations' and 'this number of bits' to program in Gen.). Multiplying this sawtooth by 8 gives us a minimum of 0, and a maximum of 8 (it just makes the 'height' of the sawtooth bigger), and this is used for timing elsewhere in this patch. For a four step sequencer then we need it to go from 0 to 4, and this time I'm gong to do it sensibly - by multiplying by a half!

(Notice that when I multiply the 'time between taps' measurement, then this affects the tempo, but multiplying the sawtooth waveform that the phasor object produces just changes its size (or amplitude in tech-speak).)

The sawtooth that goes from 0 to 4 once every bar is at point (J) in the Gen code and in the timing diagram. The final object of the 'ceil' box, and this just converts the sawtooth into the integer equivalent. It does this rather generously, and so it outputs 1 whilst the sawtooth goes up from 0 to 1, then 2 whilst the sawtooth goes up from 1 to 2, and so on. 'Ceil' is shorthand for 'ceiling', which explains why it takes the high value! Notice that it never outputs 0, so all the time that the sawtooth is less than 1, the 'ceil' object is outputting 1.


So at point (K), the output of the 'ceil' box only has four direct values: 1,2,3 and 4. We will use these to make the step sequencer choose values from the four rotary controls. The 'selector' object box is like a four-way switch: only one input is connected to the output at one time, and the control input (on the left hand side) controls which switch is closed. So when we connect the four rotary controls to the inputs of the 'selector' object and connect the 1,2,3,4 stepped sawtooth waveform into the control input, then the selector switch will scan across the four rotary controls at a rate set by the tap tempo.



I have to apologise at this point. In their most basic form, sequencers really are exactly this simple. They repeatedly scan across a number of controls, getting the value from each control, and outputting it. Look at the Gen code and follow the text above again if you aren't sure that the code is just a direct translation of what a sequencer does.

Debugging

I mentioned earlier that I would show how debugging works in Gen, and you probably wondered how I know what the waveforms at points A, J and K actually look like... To do this, you just add extra outputs ('out' objects) in the Gen code, and then connect these outputs to scope or number objects in the Max environment, so that you can look at the waveforms.

So here's a close up of the J and K points:


So the point that I have labelled as 'J' previously is now connected to an added 'out' object: 'out3' in this case, and the 'K' point is connected to 'out4'. In the Max environment, then we just use scope~ objects to see what the waveforms look like:


The 'out3' output shows the sawtooth waveform output of the phasor object, and so is connected to a 'scope~' object so we can see what it looks like. (I then turned this into the diagrams used earlier).

The 'out4' output is also connected to a number box, so that I can double-check that the 'ceil' object only outputs 1,2,3 and 4. I didn't show that bit of the Gen code, but there's also an 'out5' being used here, but the scope~ object for that is cropped off the bottom of the screenshot.

So that's how you see what is happening inside the Gen code, and this is one way to debug as you develop your design. When you don't need the debugging any longer, then you just delete all the added 'out' objects in the Gen code.

Main timing (envelope)




The timing for the envelopes uses the same phasor object, but this time I wanted to have envelopes lasting half of the step lengths: so 1/8th notes. This is why the phasor is multiplied so that it goes from 0 to 8. You can see this at point C.

If we use the 'wrap' object, then that 0 to 8 sawtooth gets 'wrapped' into the space between 0 and 1, and we get the waveform at point D. This is a sawtooth running at 8 times the bar length, and twice the step sequencer rate: in other words - 1/8th notes. Unfortunately, the 'phasor' object outputs a rising sawtooth, and percussive sounds require a falling sawtooth, so we invert it by multiplying by -1 (the  '*-1' object ) to give point E, and then we add 1 to it ( '+ 1' ) to get point F. This is a falling 'ramp' at twice the step sequencer rate, so we need to do some more processing to get four ramps to match the step sequencer.

This is achieved by using the 'ceil' object again, and this turns the unwrapped 0-8 sawtooth into a series of numbers: 1, 2, 3, 4, 5, 6, 7, and 8, and then using the '==1' object to produce a 'gating' signal. The '==1' object is normally 0, and goes high when the input is equal to 1 - hence the '==1'. So by putting four '==' objects in parallel, we can produce gates that go to 1 for the 1st, 3rd, 5th and 7th falling ramps. Using these gates on the falling sawtooth will give us just four 1/8th note falling ramps which are perfect for using as percussive envelopes, and which are locked in sync with the step sequencer - you can see this is you compare all of the points:



So if you look at K, the the four percussive envelopes in H match exactly to the four steps in K.

Note that if you change the '==' numbers, then you can choose different timings for these notes.  I will leave it to you to work out the limitations of this approach...

Here's a screenshot from actual debugging during development, showing points B, C, G and H, all output using 'out' objects into four scope~ objects in Max.


LFO and Frequency control


The Expression control (an eternal control pedal plugged into the OWL pedal) is used to control the rate of an LFO that modulates the cut-off frequency of the 'VCF' in the audio section. This time, instead of the phasor object, the 'cycle~' object is a better choice, because it outputs a sine wave, and the smooth waveform is perfect for slow filter modulation. The Expression pedal output (from 0 to 1) is adjusted to a suitable range of rates for the LFO, and the output of the LFO (-1 to +1) is scaled and has an offset added so that it output a sine wave that goes from 0 to 1.

Audio section


The audio section takes the four pitches from the step sequencer and uses them to drive two slightly detuned sawtooth oscillators made using 'phasor' objects. These are then mixed together and fed into two low-pass resonant filters in series. The percussive envelopes from point H are fed into the same 'slide' object that has been used to 'smooth' all of the rotary control knobs and the Expression pedal input, but this time it is used to lengthen the release time by lengthening the ramp. If you change the 'i 1' object to a higher value number (e.g. i 50), then the attack time will lengthen and you won't have as percussive a sound. The LFO sine wave and the percussive envelope are scaled (LFO sweeps a 5000Hz range, whilst the envelope only sweeps through 1000Hz) and are used to control the cut-off frequency of the filters. The '1 0.8' box sets th resonance of the filter at 80% - mainly because resonant filter sweeps are a classic sound, but you can change the value if you want - although going to close to '1' will cause the filters to self-oscillate, which isn't good in this type of application (unless you want a siren effect!).

The percussive envelope is also used to drive a VCA that envelopes the output of the series of filters. A DC-blocking filter prevents any problems with very low frequencies, and the final output goes to the two main stereo outputs of the OWL pedal: called 'Out1' and 'out2'.

Conclusion

Let's go back to the beginning of this blog, and review the progress. We started by implementing a simple guitar expression/volume pedal, and we ended with a 4-step sequencer driving two detuned sawtooth 'VCOs', into a resonant 'VCF' with an AD envelope and a sine wave LFO driving the cutoff frequency, followed by a 'VCA' driven by an AD envelope. All in a tiny pedal box, and there isn't very much code - there are just 57 of those little Gen object boxes at the op level, and the 'Tap Tempo' adds a few more.

For me, the hardest bit was figuring out how to compile the finished code and get it into the OWL pedal, which involves going to the Rebel Technology site and using a web interface. Once you've got the hang of it, that isn't difficult either - and Rebel Technology have lots of video tutorials on YouTube so you can see what to do.

So what was the best bit? Actually, figuring out how to do all of the timing by using phasor-based sawtooth waveforms was my favourite activity. Putting those extra 'out n' objects into the Gen patch and then looking at the waveforms in the outer Max patch was just like probing a circuit with an oscilloscope. Most amazing of all - working at 48 kHz wasn't anywhere near as scary as I expected!

I hope that you have been inspired to consider looking at programming an OWL. There is a lot of information on the Rebel Technology web-site, and the forum is full of people who can help. Have fun!

Links

Things mentioned in this blog posting:

Cycling '74 Gen

Mod Devices MOD Duo

Rebel Technology OWL Pedal

Rebel Technology OWL Modular

SynthFest UK

Native Instruments Reaktor

Flintpope

Compelling problems - making things happen in novels

Hello World!

And finally!

If you have got this far down the page, then you  might be interested in the previous blog posting on the OWL pedal - How to add a footswitch input!



Buy me a coffeeBuy me a coffee
